xadow seeedstudio－3軸加速度計400 gデジタルデジタルモーション自作メーカーのオープンソースbooole

商品説明

デジタル2、シリアルインターフェースの標準出力を持つ。装置の特徴は、超低電力動作モードの先進の省電力と3へのスマートな

More information in English:

The H3LIS331DL is a low power high performance 3-axis linear accelerometer belonging to the "nano" family, with digital I2C serial interface standard output. The device features ultra low power operational modes that allow advanced power saving and smart sleep to wake-up functions. The H3LIS331DL has dynamically user selectable full scales of ±100g/±200 g/±400 g and it is capable of measuring accelerations with output data rates from 0.5 Hz to 1 kHz.
Features
Wide power range DC2.2V to 3.6V
Xadow outline
3 axis sensing
Small, low-profile package: 3×3×1mm TFLGA
Low power 300?A at 3.3V (typical)
±100g /±200 g /±400 g dynamically selectable full scale
I2C digital output interface
10000 g high shock survivability
ECOPACK®RoHS and "Green" compliant
Documents
Please visit our wiki page for more info about this product. It will be appreciated if you can help us improve the documents, add more demo code or tutorials. For technical support, please post your questions to our forum.
